EDM NOTCHES

Utilizing our Electrical discharge machining processes we are able to machine notches and holes of varying sizes to meet the needs of our customers.

NDT Calibration Blocks Overview

NDT (Non-Destructive Testing) calibration blocks are essential tools used to ensure the accuracy and reliability of NDT methods. These blocks serve as reference standards for various testing techniques, including ultrasonic testing, radiographic testing, and eddy current testing.

Types of NDT Calibration Blocks

TYPES OF NDT CALIBRATION BLOCKS infographic 3

Key Features of NDT Calibration Blocks

Material Composition: Typically made from materials similar to those being tested, such as steel or aluminum, to ensure compatibility.
Known Flaws: Many calibration blocks include artificial flaws (like notches or holes) to provide a reference for defect detection.
Standardization: Calibration blocks are often manufactured according to industry standards (e.g., ASTM, ASME) to ensure consistency and reliability.

Applications of NDT Calibration Blocks

Quality Control: Used in manufacturing and construction to ensure that materials meet safety and quality standards.
Maintenance: Regular calibration of NDT equipment helps in maintaining the integrity of structures and components over time.
Research and Development: Used in developing new NDT techniques and improving existing methods.

Pros & Cons of Using NDT Calibration Blocks

Pros of Using NDT Calibration Blocks infographic

Cons of Using NDT Calibration Blocks infographic

CONTACT US ABOUT EDM NOTCHING

NDT calibration blocks play a crucial role in maintaining the effectiveness of non-destructive testing methods. If you have specific questions about types, standards, or applications, feel free to ask!
